The Graupner remote control mc-28 HoTT is a console transmitter for the advanced model sportsman. The mc-28 is suitable for almost all models and offers features that are also suitable for functional model builders on land and on water. 16 control functions, 120 internal model memories, integrated telemetry and voice output, as well as the fast and secure bi-directional transmission of Graupner HoTT 2.4 GHz technology, make the mc-28 a true all-rounder.The mc-28 remote control has an internal circular polarized patch antenna with very high range and reliability. Likewise, the digital and temperature-calibrated Hall sensor stick units have excellent durability, reliability and precision. Two large, high-contrast displays provide information on telemetry data and parameters at all times and allow quick and easy programming.The switches and buttons of the remote control can be freely assigned and thus individually adapted. 12 mixers are available for programming. 8 switching phase programs with announcement function can be adapted and named for each model.Thanks to the micro-SD card and micro USB interface, telemetry data and model memory can be imported and exported. Upgrades of the computer system are also carried out easily.8 switching phase programs can be individually adapted and named for each model, the switching time can be programmed separately. Functional model builders can use the phases to switch function groups. e.g. on an excavator, in one phase the driving functions are controlled by the sticks and after switching, the sticks are available for the body functions.3 ring limiters for Voith-Schneider or Schottel drives and similar. The ring limiter avoids oversteering of the drives at certain stick positions to avoid damage to the VSP or to ensure a homogeneous speed of the propeller in the Schottel drive when using our Schottel control 1762 in combination with a brushless motor.Multi-channel function: For switching up to 16 additional functions or up to 8 additional servos, two of the classic multiswitch decoders or multipropdecoders are integrated in the software. For control, all available switches or encoders can be used and up to 4 additional switches can be retrofitted with the corresponding adapter cables for UVR switches 33000.16/-17. The multichannels can be controlled by our sound modules 2386.F and 2386.S, the light module 2381, the Nautic-Expert switching module 4159, 16 channel switching module 3972 and the 4 channel proportional module 3973.General features:- Microcomputer remote control system in latest 2.4 GHz Graupner HoTT technology- circular polarized patch antenna- Temperature calibrated billet aggregates in the double ball bearing aluminium billet aggregates- Vibrating alarms- Charging via MicroUSB with LED charge indicator- Model types: flight model, helicopter, copter, vehicle, boat- Voice output by switch operation or switching phase change with a choice of over 400 voice outputs and up to 40 user-definable voice outputs- Up to 10 user-definable alerts- 10 different vibration alarms for telemetry alerts, timer, RF signal, voltage alarm- Return channel speed for towing or camera helicopter with several transmitters and receivers adjustable in the model- Music player via programmable start/stop switch- Bidirectional communication between sender and receiver- Wireless L/S function- different languages (German, English, French, Italian, Spanish) possible via software update For availability of the corresponding language see download area.- Storage of telemetry data with date and time- Servo cycle times for digital servos of 10ms selectable.- Ultra-fast response times due to direct and reliable data transmission from the main processor to the 2.4 GHz transceiver. No additional delays due to detours via a module processor.- Operation and programming based on the proven concepts of the mc-32- A high-contrast blue illuminated graphic display guarantees perfect control of the setting parameters such as model type, model memory, clocks and operating voltage.- 16 control functions- Free assignment of all switches- 120 model memories- 10 switches/buttons, of which two 3-step switches long, four 2-step switches, 2 buttons long, 2 buttons on the back and 2 sliders and 2 lateral rotary encoders- Mode 1 to 4 freely selectable- CAP-TOUCH control panels with key-lock function against unintentional operation.- Numerous telemetry, programming and evaluation functions directly in the transmitter display- Voice output can be called up via freely programmable switches- Extensive programs for wing and helicopter models- Swashplate limiter- Switch "Monitor" for control of all switches and encoder switches- 12 mixers, freely programmable for wing models and helicopters, each with freely selectable input and output functions, 4 of them curve mixers with 5-point curve technology in 1% steps, thus easily set and adjustable curve values for max. 5 points for throttle, pitch, tail or other non-linear travel. The CPU calculates a real rounded ideal MPC (Multi-Point-Curve) mixer curve with a sophisticated polynomial approximation method.- 8 switching phase programs with announcement function can be individually adapted and named for each model, the switching time can be programmed separately.- SUPER-SERVO menu with perfect overview of all servo setting data and simple parameter correction for 4 levels (direction of rotation, center position, servo travel separated on both sides and travel limitation separated on both sides for 16 servos with a total of 96 setting options)- SUPER-DUAL-RATE, EXPO menu with 36 possible setting variants, for 3 servo functions and 6 flight phases.- Practice-optimized multi-function menus for wing and helicopter models. Entering the number of aileron and flap servos automatically programs all necessary mixer functions in the multi-function wing menu. Differential aileron mixer, butterfly mixer, dual flap mixer, automatic gyro set function and other special functions- Helicopter swashplate mixer for 1-, 2-, 3- or 4-point linkage.- Fail-safe monitor for 16 servo functions- Comfortable clock menu . Stopwatch system, alarm timer, countdown timer, lap counter etc. 2 time and 1 lap/time value can be displayed.- Stopwatch with history : In addition to the lap counter there is a time 1 which records the switch-on times and a time 2 which records the ON and OFF switch-on times separately.- Transmitter operating time timer is automatically set to zero by the battery charging process of the transmitter.- Switch assignment of the flight phase switches: Now 6 switches, 2 of them with priority function . The designation of each switch combination is freely selectable. Thus the number of flight phases is independent from the number of flight phase switches.Maximum safety- Extremely high range: 3000m (down or forward > 1000m)- FHSS, frequency hopping over up to 75 channels- Maximum noise immunity through optimized frequency hopping, wide channel spreading and antenna diversification- Intelligent data transmission with correction function- Range test and warning function- Low voltage warning- Numerous fail-safe functions- Key-Lock function to prevent unintentional menu changesHighest precision- Shorter reaction times can be set (10ms period time)- No additional delays caused by module processors. All hopping management is performed directly by the 32-bit main processor.- Synchronous servo run possible by simultaneous control of the servo outputs in blocks of 4 Unique pilot feeling- Largely delay-free control reactions through direct processing- Telemetry evaluation in real time- Optional voice output of clocks, telemetry data and warnings via headphone output- Repeat function and further function of the voice output programmable via freely assignable switches- Preselection of the language output to be output- Separately adjustable volume for beeps and voice output- Integrated telemetry display with 8 x 21 characters or 128 x 64 dots, optionally in text or graphic form- Display illumination duration: ALWAYS, 30s, .60s, 90s, 120s- Micro-SD card slot for storing telemetry data similar to a black box and for expanding the model memory- PC software for evaluation or display of telemetry data via download- Sum signal at the highest receiver output programmable for L/S function, satellite receiver, simulators, paddleless rod systems etc.- Binding dependent on model memory, except for copied model memories- Wireless teacher/student function- 3 flight phases programmable- Swashplate limiter- Motor off function- Numerous surface model and helimic mixersOther features- Simple and extremely fast binding- Free channel assignment (channel mapping), transmitter and receiver mixing functions and all servo settings easily programmable- Binding of any number of receivers for channel expansion (max. 16 channels). The last bound receiver sends the telemetry data.- Future-proof through update capability via PC interface 33028.77

The Graupner mc-28 HoTT remote control is the model for the advanced model athlete. The mc-28 is suitable for almost all models. 16 control functions, 120 internal model memories, integrated telemetry and voice output as well as the fast and secure bi-directional transmission of Graupner HoTT 2.4 GHz technology make the mc-28 a true all-rounder.The mc-28 remote control has an internal circular polarized patch antenna with very high range and reliability.The temperature calibrated Hall sensor stick units also have excellent durability and reliability.Two large, high-contrast displays provide information on telemetry data and parameters at all times and enable fast and easy programming.The switches and buttons of the remote control can be freely assigned and thus individually adapted. 12 mixers are available for programming. 8 switching phase programs with announcement function can be adapted and named for each model.Thanks to the micro-SD card and micro USB interface, telemetry data and model memory can be imported and exported. Upgrades of the computer system are also carried out in an uncomplicated manner.Features:Microcomputer remote control system using the latest 2.4 GHz Graupner HoTT technologyCircularly polarized patch antennaTemperature calibrated billet units in the double ball bearing aluminium billet unitsvibration alarmsCharging via MicroUSB with LED charge indicatorModel types: model aircraft, helicopter, copter, vehicle, boatVoice output through switch operation or switching phase change with a choice of over 400 voice outputs and up to 40 user-definable voice outputsUp to 10 user definable alerts10 different vibration alarms for telemetry warnings, timer, RF signal, voltage alarmReturn channel speed for towing operation or camera chopper with several transmitters and receivers adjustable in the modelMusic player via programmable start/stop switchBidirectional communication between transmitter and receiverWireless L/S functiondifferent languages (German, English, French, Italian, Spanish) possible via software update. For availability of the corresponding language, see download area.Storage of telemetry data with date and timeServo cycle times for digital servos of 10ms selectable.Ultra-fast response times through direct and reliable data transmission from the main processor to the 2.4 GHz transceiver. No additional delays due to detours via a module processor.Operation and programming based on the proven concepts of the mc-32A high-contrast blue illuminated graphic display guarantees perfect control of the setting parameters such as model type, model memory, clocks and the operating voltage.16 control functionsFree assignment of all switches120 model memories10 switches/buttons, including two 3-step switches long, four 2-step switches, 2 buttons long, 2 buttons on the rear and 2 sliders as well as 2 lateral rotary encodersCAP-TOUCH control panels with key-lock function against unintentional operation.Numerous telemetry, programming and evaluation functions directly in the transmitter displayVoice output can be called up via freely programmable switchesExtensive programs for surface and helicopter modelsswash plate limiterSwitch "monitor" to control all switches and transmitter switches12 mixers, freely programmable for surface model and helicopter, each with freely selectable input and output functions, including 4 curve mixers with 5-point curve technology in 1 % steps, thus easily set and adjustable curve values for max. 5 points for throttle, pitch, tail or other non-linear travel. Using a sophisticated polynomial approximation method, the CPU calculates a real rounded ideal MPC (multi-point curve) mixer curve.8 switching phase programs with announcement function can be individually adapted and named for each model, the switching time can be programmed separately.SUPER SERVO menu with perfect overview of all servo setting data and simple parameter correction for 4 levels (direction of rotation, middle position, separate servo travel on both sides and separate travel limit for 16 servos with a total of 96 setting options)SUPER DUAL RATE, EXPO menu with 36 possible setting variants, for 3 servo functions and 6 flight phases.Practice-optimized multi-function menus for wing and helicopter models. Entering the number of aileron and flap servos automatically programs all necessary mixer functions in the multifunction area menu. Differential aileron mixer, butterfly mixer, dual-flap mixer, automatic gyro set function and other special functionsHelicopter swashplate mixers for 1-, 2-, 3- or 4-point linkage.Fail-safe monitor for 16 servo functionsComfortable clock menu. Stopwatch system, alarm timer, countdown timer, lap counter etc. 2 time and 1 lap/time value can be displayed.Stopwatch with history : In addition to the lap counter, there is a time 1 which records the switch-on times and a time 2 which records the switch-on and switch-off times separately.Transmitter operating time timer is automatically set to zero by the transmitter's battery charging process.Switch assignment of the flight phase switches: Now 6 switches, 2 of which have a priority function. The designation of each switch combination is freely selectable. This makes the number of flight phases independent of the number of flight phase switches. HoTT- is the synthesis of know-how, engineering and worldwide tests by professional pilots. A 2.4 GHz system that points the way for the future of RC model making.HoTT- Hopping Telemetry Transmission is safety with up to 75 channels HoTT- uses frequency hopping spread spectrum technology. (FHSS)HoTT- offers integrated telemetry in real time (expandable).HoTT- is fully programmable with the help of the Smartbox.System Features:- Simple and extremely fast binding- Range test and undervoltage warning function- Extremely wide receiver operating voltage range from 3.6 V to 8.4 V (functional up to 2.5 V)- Failsafe, free channel mapping- Binding of any number of receivers for channel expansion (max. 32 channels)- Up to 4 servos can be controlled simultaneously in blocks with a servo cycle time of 10 ms (Digital servos only!)- Maximum noise immunity due to optimized frequency hopping and wide channel spread- Extremely fast rebinding, even at maximum distance- Telemetry evaluation in real time- Future-proof due to update capability via USB interface S1033.77

The transmitter Graupner mc-26 HoTT is the model for the advanced model fans. The mc-26 is suitable for almost all models. 16 control functions, 120 internal model memories, integrated telemetry and voice output as well as the fast and reliable bi-directional transmission of the Graupner HoTT 2.4 GHz technology, it all makes themc-26 a true all- rounder.The mc-26 remote control has an internal circular polarized patch antenna with very high range and reliability.The control sticks, with double ball-bearing on each axle, ensure an optimal control feeling.Two large, high-contrast displays inform you about telemetry data and parameters at all times and enables fast and easy programming.The switches and buttons of the remote control can be freely assigned and thus individually adapted. 12 mixers are available for programming. 8 Switch phase programs with announcement function can be adapted and named for each model.Thanks to micro-SD card and micro USB interface, telemetry data and model memories can be imported and exported. Also upgrades of the firmware are carried out so uncomplicatedly.FeaturesMicrocomputer remote control set implemented with the very latest 2.4 GHz Graupner HoTT technologyRing limiter and channel sequencerBidirectional communicationbetween transmitter and receiverWireless T/P function6 different languages (German, English, French, Italian, Spanish and Dutch) available via software update. For the availability of a given language, go to the Download area.Storage of telemetry data with date and timeServo cycle times of 10 ms can be selected for digital servosUltra-fast response times through direct and reliable transmission of data from the main processor to the 2.4-GHz transceiver. No additional delays due to detours via a module processor.Operating and programming are similar to the proven concepts implemented in the mx-24A high-contrast, blue-illuminated graphic display ensures perfect control of parameter settings such as model type, model memory, timers and operating voltage.12 control functionsFree assignment of all switches120 model memories10 switches/keys, including two long 3-position switches, four 2-position switches, 2 long keys, 2 keys on the rear and 2 slider regulators as well as 2 side rotary controlsModes 1 to 4 freely selectableCAP TOUCH operating elements with key lock function to prevent unintentional operation.Numerous telemetry, programming and evaluation functions are presented directly on the transmitters screenVoice output can be called up via freely programmable switchesExtensive programs for fixed-wing and helicopter modelsSwashplate limiterMonitor switch to check all switches and control switches12 freely programmable mixers for wing or helicopter models, each with freely selectable input and output functions, including 4 curve mixers with 5-point curve technology in 1% increments, resulting in curve values that are easy to set and adjust at up to 5 points for throttle, pitch, tail or other non-linear actuations. The processor in the CPU employs an ingenious method of calculating polynomial approximations for truly-rounded, ideal MPC (multi-point curve) mixer curves.7 flight-phase programs can be individually adapted for each model and given a name. The switchover time is programmable separately.SUPER SERVO menu with a perfect overview of all servo setting data and simple parameter correction for 4 levels (direction of rotation, mid-point setting, separate servo travel on both sides and separate travel limiting on both sides for 12 servos with a total of 72 possible settings)SUPER-DUAL-RATE, EXPO menu with 36 possible settings for 3 servo functions and 6 flight phases.Highly practical multi-function menu for fixed-wing and helicopter models. Entry of the number of aileron and flap servos automatically programs all necessary mixer functions in the multi-function Wing mixers menu. Differential aileron mixer, butterfly mixer, dual-flap mixer, automatic gyro set function and other special functionsHelicopter swashplate mixer for 1, 2, 3, or 4-point steering.Fail-safe for 12 servo functionsConvenient timers menu. Stopwatch system, alarm timer, countdown timer, laps counter, etc. Two timers and one lap counter/timer can be displayed at the same time.Stopwatch with history: in addition to the lap counter there is a time 1 which captures the ON time and a time 2 which records the ON and OFF times separately.The transmitters operating time timer is automatically reset to zero by the battery charging process.Flight phase switch assignments: now 6 switches, 2 with priority function. Every switch combination can be named freely. This makes the number of flight phases independent of the number of flight phase switches.Linearising switchplate servos: electronic compensation for non-linear travel of swashplate rotary servos.Tail type normal, V-tail, Delta/flying-wing and 2 EL Sv 3+8 (which immediately makes 2 coupled elevator servos available without using free mixers or dual mixers)Flap count up to 4 AIL/4 FL: Full support of 8 wing servos, now even without use of free mixers.Flight phase switching delay, can be switched off: the delay time can be switched off for individual channels flight phase by flight phase (e.g. for motor off in electric models or to activate/deactivate helicopter head lock).16 phase namesFixed-wing mixer: New concept for the multi-flap menu to simplify settings of up to 8 wing servos on a flight-phase-specific basis in a comprehensible manner without requiring the use of free mixers.Number of flight phases: (fixed-wing: 7, helicopter: 6 + AR)Phase trimSwitchable Snap-Flap mixer EL => FL with a new offset function for easy course corrections and fast turns3 ring limiters for Voith-Schneider and similar drivesChannel sequencer for 3 channels for folding motors and landing gear doorsLogical switchesTrim memoryMulti-channel function to expand channels for up to 14 additional channelsMusic player and internal speaker for voice output and musicSwapping of servo assignment at receiver output on transmitter side and receiver sidePPM signal adjustable at the data outputModel memories of the mx-20 can also be loaded directly into the mc-20. To do so, simply copy the model memories on the PC to the appropriate directory. Then the switches and controls must be newly assigned because of the different hardware.CharacteristicsLinearization of swash plate servos : Electronic compensation of the non-linear path of swash plate.Tail configuration type normal, V tail, delta / flying wing, 2 ALE Sv 3 + 8 (two interconnected elevator servos are available immediately without the use of free mixers / crossmixers)Flap number up to 4 AILE / 4 FLAP: Full support of 8 wing servos, now also without the use of free mixers.Switch-off of the flight phase changeover delay: The deceleration time can be switched off for individual channels in the flight phase mode (eg for motor-off in the case of electric models or head-lock activation / deactivation for helis).16 phase namesWing mixer: Newly designed multi-flap menu for simplest settings of up to 8 wing servos in a flight-specific and clear manner even without the use of free mixers.Number of flight phases: (airplane: 8, Heli: 7 + AR)Phase trimmingSwitchable Snap Flap Mixer ELE -> FLAP with new offset function for easy course corrections and fast turning3 ring limiters for Voith-Schneider drives and similarChannel sequencer for 3 channels for folding propulsion and landing gear flapsLogic switchesTrim memoryMultichannel function channel expansion for up to 14 additional channelsMusic player and internal speaker for voice output and musicInterchangeable servo assignation on the receiver output from receiver side and transmitter sidePPM signal can be set at the data output HoTT- is the synthesis of know-how, engineering and worldwide tests by professional pilots. A 2.4 GHz system that points the way for the future of RC model making.HoTT- Hopping Telemetry Transmission is safety with up to 75 channels HoTT- uses frequency hopping spread spectrum technology. (FHSS)HoTT- offers integrated telemetry in real time (expandable).HoTT- is fully programmable with the help of the Smartbox.System Features:- Simple and extremely fast binding- Range test and undervoltage warning function- Extremely wide receiver operating voltage range from 3.6 V to 8.4 V (functional up to 2.5 V)- Failsafe, free channel mapping- Binding of any number of receivers for channel expansion (max. 32 channels)- Up to 4 servos can be controlled simultaneously in blocks with a servo cycle time of 10 ms (Digital servos only!)- Maximum noise immunity due to optimized frequency hopping and wide channel spread- Extremely fast rebinding, even at maximum distance- Telemetry evaluation in real time- Future-proof due to update capability via USB interface S1036.77

Features:HoTT (HOPPING TELEMETRY TRANSMISSION) bi-directional 2.4GHz technology75 jump frequencies for safe transmission9 channels3.5" TFT colour touch display for easy operationIntelligent speech output of telemetry data, warnings, alarms and Vario signal via loudspeakers or headphonesReal-time data transmission with optional sensors (Vario, GPS, fuel, temperature, voltage, current, speed and much more)Teacher/student system wireless or wiredBinding of several receivers possibleBall bearing billet units (total 8 units)µSD card slot for model memory expansion and telemetry data recording30 model memoriesModel copy functionUpdateable via USBModel type: helicopter, flight model (normal or delta), glider modelNumerous servo settings (travel, limit, reverse, center position)DualRate and Expo, separately adjustable for each flight phase6 flight phasesHelicopter type: 1 servo, 2 servo 180°, 3 servo 120° (2 pitch or 2 roll), 3 servo 140°, 4 servo 90°Pitch curves (7 points) separately adjustable for each flight phaseGas curves (7 points) separately adjustable for each flight phasePhase trims for pitch and gasSwash plate limiter functionSwash plate mixing function5 Linear mixer3 curve mixerNumerous model aircraft types from 1QR to 4-flap surfacesElevator: 1 HR, 2HR, V-tailSnaproll functionAileron differentiation, separately adjustable for each flight phaseButterfly functionNEW:Security:FHSS, frequency hopping over up to 75 channelsMaximum noise immunity through optimized frequency hopping, wide channel spread and antenna diversificationIntelligent data transmission with correction functionExtremely high rangeRange test and warning functionlow-voltage warningExtremely wide receiver operating voltage range from 3.6 V to 8.4 V (functional up to 2.5 V)Numerous fail-safe functionsKeylog function to prevent unintentional menu changesPrecision:Shorter response times adjustable (10ms period time)No additional delays due to module processors. All hopping management is done directly from the 32-bit main processor.Synchronous servo run possible by simultaneous control of the servo outputs in blocks of 4Pilot feeling:Largely instantaneous control reactions through direct processingTelemetry evaluation in real timeWireless teacher/student functionMore characteristics:Simple and extremely fast bindingFree channel assignment (channel mapping), transmitter and receiver mixing functions and all servo settings can be easily programmedBinding of any number of receivers for channel expansion (max. 16 channels). The last bound receiver sends the telemetry data.Future-proof due to update capability via USB interface S1005.77

All in oneThe Graupner mz-16 provides the technology and features only seen in high-end radios available as a 16 channel 2.4GHz HoTT radio. The mz-16 provides the pilot with a radio system where accuracy, control and reliability is fully integrated inside a high-tech carbon look and comfortable ergonomics transmitter.You are in controlThe mz-16 brings the same powerful features as our mz-32 radio introducing a new level of functionality where you, the user, can control almost any part of the radio. The mz-16 brings you the power to design your own screens, program your own control logic, filter your own voice notifications and even design the looks of your radio with removable colored face plates.Fly smoother with the mz-16The Graupner mz-16 provides 16 channel proportional functions and supports five different model types such as electric, gas or turbine airplanes, helicopters, multirotor, cars and even boats.It can store and load up to 999 different user models, has 8 flight-phases and 12 curve mixers which can be set global or flight-phase dependent! The machined aluminum quad bearing gimbals provide the smoothest control feel a pilot can experience which can be comfortably adjusted the way you like from the back of the radio.The mz-16 has a rock solid HoTT 2.4GHz RF system combined with a adjustable linear antenna for unmatched signal quality and extended range. The mz-16 adapts to youThe outdoor friendly 4.3-inch state of the art TFT color touchscreen ensures convenient access to all the mz-16 functions for setting up and managing your models. The highly optimized and fast performing graphical user interface is driven by a high-performance processor making access to menus and functions fast and crisp just like on your Smartphone. The intuitive touch and tap control make navigation around the menus fast, easy and fun! The mz-16 is not only fast and responsive but is also fast to load. You will be using your mz-16 from power up in no time! Designing your own screen layouts to display information or create menu shortcuts can be done on the fly by simply tapping on the screen. The mz-16 provides over hundred widgets which make up the screens that you like and fit your style for controlling your models. You can create in total six screens that better fit your needs and personal style using the tip of your finger. No programming needed! You can do it all with the mz-16! One radio for all! English, German, French, Dutch, Italian, Portuguese, Chinese, Korean, Spanish language is supported with more languages to come all in one radio!16 proportional channels and 16 digital switchesWith 16 channels the mz-16 provides unlimited functionality and control over any model that you have. You can bind two 2.4GHz receivers so you can layout and distribute the channels the way you want. For example, you can have one receiver that controls all your wing servos such as ailerons, flaps, landing gear, and lights. Just supply main power to the wing, and you are ready to go. No complicated wiring or expensive hubs needed! This provides you with a level of simplicity with the benefits of additional RF redundancy for extra peace of mind.Still need more channels but do not have enough switches to do what you want? The mz-16 also provides up to 16 digital switches that can be assigned and controlled with a single tap from the widget menu. Create as many digital switch combinations as you like for turning lights and smoke on or off, turn cranes or water guns or anything else that you need to control without using up your switches. Switching and control options are further enhanced with Logical Switches (And, Or, Equal, Not), Control Switches, Sensor Switches and Combination Switches. Each provides a new level of control to you depending on switch position, stick location or telemetry data.Voices you want to hearNeed to hear what is going on? The mz-16 provides endless options to generate almost any type of system or telemetry voice notification depending on the state of your radio such as switch positions, flight phase names, warnings, vario information and endless others. The mz-16 starts communicating with you from the moment you turn it on, informing you if a switch or control is in the wrong position for the selected model. No more surprises from collapsing landing gear, runaway motors or wrong gyro settings. The mz-16 can inform you when needed even when you forgot to bring down your landing gear or are about to run out of range or battery. Walks of shame are now a thing of the past! With over 600 installed voices and unlimited voice combinations, you can make almost any voice announcements or add as many as you want using our text to speech editor.Instant help where you need itIn need of help during setup or when something is unclear? Forget about searching through lengthy manuals or endless web searches! The mz-16 provides support right where you need it. Each menu and option have its own context-sensitive answers right on the screen. Just tap the question mark and you will be instantly presented with help and assistance. Don’t like our help screens? Make or add your own help screens with whatever content makes sense to you. The mz-16 is there for you allowing you to do and have the things you like the most.Connectivity that takes you furtherWith integrated WLAN the mz-16 is ready to connect you with the rest of the world!Connect to your wireless LAN to receive notifications about newly released firmware which are instantly downloaded and installed on your radio. Your mz-16 is always up to date with the latest and greatest! Updates can also be done with the included USB cable and our firmware upgrade studio software.Graupner takes connectivity further with a micro USB port that can charge your radio, access your included 16GB micro SD memory card where screens, models, voice files, music and screen shots can be stored.You can use the USB or DSC port also as a joystick controller for games and flight simulators. Now you can practice flying your model on your favorite flight simulator with the same radio that you use at the field! The data port on the back can be configured to output a variety of digital signal outputs like SUMD, CROSSFIRE, Smart Box, and more. Adding and using third-party modules such as long-range FPV has never been easier than with the mz-16. All Graupner HoTT receivers now also support digital serial wire output such as PPM, SUMD, and SBUS for more connectivity and better interoperability with third party flight controllers. Supported ProtocolsHOTT-PC - Smart-Box - External Monitor - SUMD - DSMX/DSM2 (Data Output) - CROSSFIREWireless ober the air setupComputers, wirers, and programming boxes are things of the past! The mz-16 HoTT wireless protocol lets you do everything right on the radio! Need to set up your telemetry, flight controller or reverse the direction of your ESC? Just use the shortcut key on the radio to access any of the connected devices, and you are immediately in business.Do this at home while setting up your model or at the field to fine-tune your settings. Enjoy the HoTT integration of third-party flight controllers and sensors like Ikon, Spirit, 3Digi, MSH-Brain, SM-Modelbau and many more for easy access using your mz-16 radio. Train your buddiesTraining your family members or friends is as easy as bind and teach! The mz-16 provides a wireless as well as wired trainer support you can use with other brand radios using the DSC port in the back. You can assign control to any of the active channels depending on your student's level and model capabilities. Passing control is easily done with a flick of a switch.HARDWARE“ Machined Aluminium Quad bearing gimbals for smooth and precise control“ Outdoor friendly 4.3-inch TFT color and touch screen“ Circular polarized patch antenna with adjustable beam angle“ 4000 mAh LiPo rechargeable battery for up to 4 hours of operation“ Micro-USB port for charging, data communication, joystick function or mass storage“ Externally adjustable stick tension and mode selection“ Internal µSD 16 Gb memory card“ Built in Wireless communication“ DSC socket for external communications (wired buddy box, flight simulators, other)“ Wireless student teacher operation“ Wireless firmware update“ Integrated speaker for voice output and telemetry notifications“ User configurable DSC and data ports (SUMD, CROSSFIRE and others)“ User assignable haptic feedback“ 5 x 3 position switches, 2 x 3 position/toggle switches, 1 x 2 position switch, 4 proportional knobs, “ 2 x lever controls, 8 assignable digital buttons“ 6 shortcut control and navigation keysSOFTWARE“ 16 proportional channels“ 999 Model memory“ 2 Receiver binding 10ms or 20ms frame rate“ Model, group or global binding modes“ Model types: Airplane, Helicopter, Multirotor, Vehicle, Boat“ 8 selectable flight modes“ 8 wing types, 6 delta wing types (total 14), 3 tail types“ Multi engine control (4)“ 6 user designable widgets dashboards (model specific or global)“ Context sensitive help text“ Airplane auto trim mode“ Text to speech with VDF editor“ Servo balancer & synchronization“ 5 phase dependent assignable trim settings and 5 trim types“ 4 phase dependent configurable timers (Start/Stop, Lap, Lap Trigger, Lap Toggle)“ 4 phase dependent quad rate and expo settings“ 12 phase dependent multi point user mixers“ 4 dual differential cross mixers“ 3 channel sequencers“ 3 channel ring limiters“ 16 user assignable digital switches“ 6 assignable combination switches“ 8 assignable logical switches“ 8 assignable control switches“ 4 snap roll mixes“ 8 wing and tail mixers and crow/butterfly function“ 9 user assignable and configurable system voice notifications“ 8 user assignable and configurable user voice notifications“ 12 user assignable and configurable control voice notifications“ 8 Sensor activated switches“ 8 User assignable and configurable voice notifications“ 4 Direct adjust control“ Dedicated vario and control menu with dead zone control“ Wireless setup of receivers, telemetry and flight controllers“ User configurable MP3 player“ Integrated file manager S1047.77

The Graupner mz-12 PRO is raising the bar for any radio in its price range. With 12 channels, 250 model memories, 5 model types, real-time voice telemetry, user announcements and 1500 mAh LiPo battery the mz-12 PRO is setting a new standard in value and performance!Easy to hold easy to useHolding the mz-12 PRO gives an instant locked feeling to the pilot. FPV and hand launch sailplane pilots will appreciate the design of the mz-12 PRO which provides better grip and accessibility to switches and controls. The included 1500mAh LiPo battery can be easily charged with the included micro USB cable.The mz-12 PRO micro USB port can be used for charging, software updates and for use as a joystick controller with supported games such as flight simulators. Now you can use the same model indoors for training purposes and outdoors to show off your new skills!Updating the mz-12 PRO with new software, user made voice notifications or user models is done with the free firmware update studio providing the user with additional flexibility and increased value.250 model memoriesNo need for storing models on SD cards or computers. With 250 model memories the mz-12 PRO provides you with almost unlimited storage for all your models. Moving models between your mz-12 PRO and computer is done with the firmware update studio where users can also share their models between their mz-12 PRO radioReal-time telemetryReal-time telemetry is already integrated in the mz-12 PRO and does not require any additional hardware for functions such as signal quality, temperature, or receiver voltage. The included Falcon 12 6-channel receiver provides telemetry functions that can be configured to notify you regarding any system changes. Graupner provides a wide selection of telemetry ESCs, modules and sensors that can immediately connect to and of our HoTT receivers and flight controllers without the need for external hub boxes or complex wiring.Add situational awareness and extra safety by easily assigning switches to telemetry functions and notifications to provide information about battery voltage, battery capacity, altitude, flight direction, speed, etc. The real-time, bi-directional HoTT transmission protocol will constantly monitor system health and notify you of any changes to the system. No more surprise situations such as sudden battery depletion or accidentally flying out-of-range!Programmable voice alertsConfigure any switch or control on the mz-12 PRO with a wide selection of voice announcements and alerts. Set up countless announcement combination options based on your needs and model conditions with flight-dependent voice triggers. Record your own voice messages to customize your experience by downloading the free Graupner Firmware Update Studio Program!The built-in speaker provides a loud and clear adjustable volume for all the radio notifications. Subsequently user can also use a headset for hearing notifications.FPV is kingThe mz-12 PRO is empowering multirotor pilots with features such as CROSSFIRE V2, race timers, telemetry and more. The included Falcon 12 receiver can be used as multirotor flight controller supporting a variety of ESC modes and multirotor configurations.Wireless setupNeed to reverse your motor direction, setup your Falcon flight controller or make telemetry settings? With the mz-12 PRO radio all these tasks can be easily done using the radio without the need for cables, computers or programming boxes! Just make all your settings changes on the fly at your shop or at the field!Five model typesAirplanes, helicopters, multirotors, boats, cars... the mz-12 PRO supports all model types! Setting up a helicopter or full house glider is easily done by simply selecting the right model type. For example, in airplane mode you can select from 4 tail types 5 wing types, 2 flight modes, 9 free mixers and 8 wing mixers.Each switch and control can be freely assigned to any channel based on preferences giving you the ultimate freedom to setup your model.Features:12 radio channels and 250 model memoriesQuad bearings gimbals for smooth operationIntegrated long range antennaMicrocomputer radio 2.4 GHz radio utilizing Graupner HoTT technologyUse of up to 75 frequency-hopping channels to ensure operating reliabilityRemoveable 1500mAh LiPo rechargeable batteryBattery charging indicator when charged with included USB cableBidirectional communication between transmitter and receiverFast 10ms frame rates when used with digital servosWireless or wired Teacher/Student link (buddy boxing)Micro USB Joystick function for flight simulator trainingModel types: Airplane, Helicopter, Multirotor, Boat and CarSupports 5 different languages (German, English, French, Italian and Spanish)Model memories can be stored and retrieved from computerIntuitive operation and programming‹ HoTTSync for exclusive and safe model operation Airplane Wing Types: 1AI, 1AI-1FL, 2AI, 2AI-1FL, 2AI-2FLAll switches and controls are user assignableRadio Switches: 2 x 3-position switches, 1 x 2 position spring loaded switch, 2 x 2 position switch, 1 analog rotary knobMode 1 to 4 freely selectableKey-lock function against unintended operation.2 programmable flight phasesHelicopter Swash plate limiterDual Rate and Expo individually adjustable and switchable during the flightWing mixers (aileron/flaps differential), (aileron rudder/flaps mixer), (elevator flap/aileron mixer), (flap elevator/aileron mixer)Multi point throttle curve in all model modesFree assignable mixers functions (5 linear mixers and 4 curve mixers)Programmable fail-safe function "Hold" or "Move to preset positions" can be set separately for each individual servo channelStopwatches / Countdown timer with alarm functionModel copy function for model memorySupported data formats on the DSC port: Telemetry, Bluetooth, CROSSFIRE V2 unidirectional S1002.PRO.77

Features:Machined-Aluminum quad bearing 4096 resolutions gimbalsExternal accessible stick tension adjustmentsReal-time SD-card data logging of critical flight informationBalanced weight distribution of radio with comfortable rubber hand gripsExternal DSC port for flight simulator connections or third party devicesExternal data port for optional Bluetooth5000 mAh LiPo batteryUpdateable firmware with Graupner Firmware Update StudioSoftware:Easy-to-use graphical programming menus3.5-inch thin-film transistor (TFT) color and touch screen12 programmable proportional channelsSupports all model types: airplanes, sailplanes, helicopters, multirotor, cars and boatsFlight phase assignable and programmable voice switchesUser created and user assignable voice filesReal-time telemetry voice announcements and alertsUser assignable switches and proportional controlsIn-flight auto trim of airplanes14 wing types for airplanes and sailplanesReady to go wing and flap mixers8 programmable mixers, 5 linear and 3 curve mixersWide range of sailplane programming: butterfly, camber, aileron differentialWireless student and teacher mode10 logical switch assignments3 channel servo sequencerDual, triple rates and exposAdjustable trim steps 0 to 10Selectable frame rates of 10ms or 20ms6 flight modes with voice announcementsMulti receiver binding for expansion and system redundancyUser adjustable mode selection (1, 2, 3 or 4)MP3 player (uses SD card up to 32 GB)HoTTSync for exclusive and safe model operationUse of up to 75 frequency hopping channels to ensure operating reliability30 model memories with almost unlimited model storage on SD memory cardSupport for digital SUMD, SBUS or SUMO (PPM) outputs for third party controllersSee it, hear it, touch itBright colors, voice announcements and a TFT touch screen is what makes the Graupner mz-24 PRO one of the most versatile radios on the market, and at a price that cannot be beat! Experience a new level of connection between you and your model with 12 channels and built-in real-time voice telemetry. Colorful menus and displays make usability easy to navigate through the menus and setup options with the touch of your finger or a stylus. Traditional navigation keys provide an old-school experience if you prefer to push physical buttons.The aluminum quad bearing 4096 resolution gimbals were machined with high-precision and are adjustable for smooth and accurate flight control. Safe and worry-free flights are achieved with our HoTT (Hopping Telemetry Transmission) technology by hopping over 75 2.4 GHz channels to secure the most reliable, interference-free operating channel. The red highlights adds a beautiful splash of color around the control sticks adding style to your gear.Real-time telemetryReal-time telemetry is integrated in all our HoTT radio systems. The mz-24 PRO does not require any additional hardware for functions such as signal quality, temperature, or receiver voltage. The included 8-channel and 6-channel receivers provide telemetry functions that can be configured to notify you regarding any system changes. Graupner provides a wide selection of telemetry ESCs, modules and sensors that can immediately connect directly to your HoTT receivers without the need for external hub boxes or complex wiring. Our third-party partners provide additional telemetry products that work seamlessly with your mz-24 PRO HoTT radio.Add situational awareness and extra safety by easily assigning switches to telemetry functions and notifications to provide information about battery voltage, battery capacity, altitude, flight direction, speed, etc. The real-time, bi-directional HoTT transmission protocol will constantly monitor system health and notify you of any changes to the system. No more surprise situations such as sudden battery depletion or accidentally flying out-of-range! During flight, important data is logged on the SD memory card which can be analyzed to improve your system's reliability and performance.Programmable voice alertsConfigure any switch or control on the mz-24 PRO with a wide selection of voice announcements. Set up countless announcement combination options based on your flying needs and airplane conditions with flight-dependent voice triggers. Record your own messages to customize your experience by downloading the free Graupner Firmware Update Studio Program!Logical switchesControl your model in every conceivable condition with logical switch positions or controls, adding a new dimension of control to the way we fly our models. For example, set up a logical switch that will not allow your gear to come down unless you have your flaps in the landing position. The AND/OR switch combinations are limited only by your imagination.Servo sequencerSet and save a series of up to nine timed events with the three-channel servo sequencer. With the flip of a trigger switch you can retract landing gears, open/close gear doors and have your pilot turn and wave to your adoring fans.Auto trim and stepIt's easy to trim your airplane, especially during its first flight! Just fly your airplane at level attitude and trigger the auto trim switch. The mz-24 PRO will automatically set the trims on your airplane. Freely assign the auto trim function to any switch for maximum flexibility during flight. The mz-24 PRO provides additional options for controlling trim settings, resulting in a perfectly trimmed model.Wireless setupNeed to reverse your motor direction, setup your flight controller or make receiver settings? The mz-24 PRO radio can easily setup, program, and change all Graupner HoTT products remotely, eliminating the need for cables, computers or programming boxes!Six model typesAirplanes, sailplanes, helicopters, multirotors, boats, cars...the mz-24 PRO supports all model types! Each has been specially programmed with different menu function specifications unique to that particular model. Further enhance the model with assigned voice triggers using specially uploaded (or custom tailored) files. S1006.PRO.77

The Graupner mz-10 remote control is a inexpensive and yet very reliable remote control. The 5 control functions allow the operation of numerous flight models. The mz-10 has Graupner HoTT technology, a very long range and a wide operating voltage range (up to 4.8 volts). Bright LEDs indicate the channels, the binding status and the model setting (4 types: normal, delta, v-tail or 2 ailerons). The mz-10 has 4 stick modes.The transmitter antenna is protected and integrated in the handle.The instructions in German, English, French and Italian are included. S1042.77

Graupner mc-32 EX HoTT remote control (32-channels and 64 digital switches).The Graupner mc-32 HoTT console transmitter with its 32 channels is a high-end transmitter for true professionals and modelers who value maximum safety, stable telemetry, intuitive programming and maximum functionality. TAILOR-MADE FOR YOUR REQUIREMENTSThe huge range of hardware and software features offers an almost limitless variety. Whether it's functionality and switch assignment, the screen layout that can be customized down to the last detail, or the extensive voice output - you can adapt your transmitter to your preferences and habits. And that without programming knowledge or thick manuals. Fast, easy and intuitive! Flexibility and configurability are the hallmarks of the Graupner mc-32 EX!FULL CONTROL - FULL FUNCTIONALITYThe Graupner mc-32 EX HoTT comes without additional modules on real 32 channels in the basic equipment! This gives you limitless functionality and control for any type of model. Choose from 5 different model types such as flying models (electric, combustion or turbine powered), helicopters, multicopters, vehicles and boats. Store your different models on each of the 999 model memories. 12 phases (levels) and 16 curve mixers can be programmed globally or phase-dependent.Need more channels and running out of switches? The mc-32 EX includes an additional 64 digital switches that are assigned and controlled with a simple tap, using the widget menu. Create nearly infinite digital switch combinations to control lighting or smoke, turn cranes or water cannons, or just about anything you can think of without running out of switches. If that's not enough, you can add up to 7 more switches by simply plugging them in.The logic switches (AND, OR, EQUAL, UNEQUAL, AND max, OR max, XOR max,...) with adjustable time delay and linear or digital switching output, encoder and combination switches increase the variety of switching and control possibilities enormously. Each of these switches controls the functions you want to realize depending on its switching position or the stick position. You define how each switch should be named. BIND UP TO 4 RECEIVERS AT THE SAME TIMEBind up to four 2.4GHz receivers at the same time and define the distribution of the channels as you like. For example, one 6-channel receiver can be installed per wing and control the ailerons, airbrakes, landing gear and lights. All that is then required is to route the power supply to each wing and you are ready to go. No complicated cable routing or expensive distributor is needed! This provides simplicity coupled with all the benefits of RF redundancy.PERFECTLY MATCHED HARDWAREThe quadruple ball bearing stick units and with a Hall sensor resolution of 2400 steps (equivalent to a 0.5us servo pulse change), provide a pure feeling of control over your model. The integrated 3-step switches offer convenient switching of phases (levels), motor, autotrim or other user-definable functions. The power units can withstand bad weather conditions and are easily and comfortably accessible from the back of the transmitter to adjust them to your preferences.The transmitter can also be equipped with 4D sticks. However, one of the two 4D encoders is then connected instead of the upper roller-shaped encoder in the transmitter, which can be connected to any other free slot instead.ERGONOMIC HOUSINGYou expected a completely new design for the new mc-32 EX? The entire Graupner team unanimously decided against it without a long discussion! Because the design of our console transmitters was created in 2008 by a Swabian design office together with world champion pilots, who paid full attention to the ergonomics of the transmitter. Every switch, every control sits exactly in the perfect position to the millimeter, which was determined in numerous studies with model sport professionals. And even for long-time mc users, the new mc feels immediately familiar in the hand. The mc-32 EX is housed in a sturdy aluminum frame. The switches, buttons and displays are housed in a high-quality plastic case that retains its pleasant feel even in extreme temperatures. FULL POWER UP TO 10 HOURSThe mc-32 EX HoTT is equipped with a dual, redundant 2.4 GHz RF system. A circular patch antenna and a linear antenna provide excellent signal quality and increased range. The included 9000mAh LiPo battery allows for a long day of flying with more than 10 hours of operation! For hardcore pilots, the battery is also replaceable. So if you can do without sleep, you can get through a full day on 2 battery charges. By the way, when you change the battery, it doesn't matter how the plugs are plugged in. The mc-32 EX is protected against reverse polarity by the circuit board layout.YOUR INDIVIDUAL TOUCH DISPLAYThe large 4.3-inch TFT color touch screen provides convenient, easy and quick access to all the functions you need to set up your model perfectly for you. You have everything in view at all times! Even in direct sunlight, the display is perfectly readable. The highly optimized graphical user interface behaves like your smartphone and gives you access to all menus and functions. Fast and clear, powered by a high-performance processor.Intuitive touch and swipe controls make navigating menus quick and easy. Design your own up to 6 screens to display information important to you or generate menu accesses - all with a simple tap of the screen. Custom widget pages can be toggled using the left buttons and a freely programmed digital button or switch.The mc-32 EX HoTT includes over 100 widgets that let you customize your screens the way you want. - without programming on the PC! Fast - easy - intuitive. The menu is available in English, German, French, Italian, Dutch, Portuguese, Czech, Chinese and Korean. EXPAND YOUR HORIZON WITH YOUR SMARTPHONENeed more data at your fingertips? A large part of our daily life is done with our smartphone. We offer you the possibility to integrate your smartphone into your RC experience. At the top edge of the aluminum frame is a metal bracket to which an optionally available smartphone mount can be attached. Once your smartphone is securely plugged in and connected via Bluetooth or USB cable, you can read out important data via the Graupner HoTT Viewer app during RC action. The smartphone is positioned on the transmitter in such a way that your gaze does not have to stray too far from the model. Due to the steep viewing angle of the cell phone, the display is easy to read even in direct sunlight. The optional cell phone holder replaces the old mini display at the top edge of our old console transmitter generations. In practice and in numerous tests with modelers, it has been shown that this small display does not offer much added value. With your smartphone you get a larger, better readable and more functional display.ENORMOUSLY EXTENSIVE VOICE OUTPUTHear what's going on! The mc-32 EX HoTT offers virtually unlimited configurable voice output options for the telemetry system and transmitter status itself. Switch positions, flight phases, warnings, vario tones, telemetry information, custom voice outputs and much more. The mc-32 EX interacts with you from the moment you turn it on, informing you of incorrect stick or switch settings for the selected model. No surprises from landing gear collapsing, motors running up, or incorrect gyro settings. The mz-32 will even alert you if you forget to extend the landing gear, are in danger of falling below range, or the battery voltage is getting dangerously low. These problems are a thing of the past! With over 600 voice files installed, you get an incredible variety of possible combinations of voice outputs. If needed, you can use a text-to-speech editor to create as many of your own files as you like and edit them to your liking.WIRELESS TEACHER/STUDENT FUNCTIONThe future of our beloved hobby belongs to the next generation. To this end, it is important to gently introduce young people and newcomers to model sports. For first RC attempts it is a good idea to support the new pilot with a second remote control to help or to be able to intervene in case of emergency. All our Graupner transmitters can be connected to each other with a teacher/student function. And completely wireless!ALWAYS UP TO DATEOf course, as an mc-32 EX user, you will be provided with the latest functions and updates. Completely free of charge! As soon as an update is available and your transmitter is connected to the WLAN, you will get an info on the transmitter display if you want to perform the new update by pressing a button. TIP: If you want to perform an update, it is advisable to ensure sufficient battery capacity or direct power supply. If your transmitter runs out of power during the update, this is not a problem. The update can be continued at the same point.QUICK HELPNeed help with programming or settings? You don't need thick manuals or hours of searching the internet! The mc-32 EX offers help directly where you need it. For each menu and each option there is a separate help text directly on the screen. Tap on the question mark and you will get the corresponding help and support. You want other help texts? The texts can easily be customized or even extended. The mc-32 EX is there for you and gives you the possibility to do what you want and like best. Connectivity that takes you further!Hardware features- 4 ball bearing aluminum sticks with hall sensors and a resolution of (12-bit) 2400 steps or 0.5us servo pulse for precise control- Adjustable mode and spring forces of the sticks by simply opening the back panel, without any screws at all- Sunlight-readable 4.3-inch TFT color touch display- 2 redundant 2.4 GHz RF modules- One circular polarized patch antenna and one transverse mounted antenna with adjustable beam angle- 9000mAh 1S3P LiHV battery for transmitter operating times of approx. 10h- USB type-C port with charging function, PC interface (e.g. for updates, flight simulators, etc.), USB joystick function, mass storage function- Headphone jack- WLAN-capable: for firmware updates- Bluetooth-capable (e.g. for Bluetooth headphones or Android HoTT Viewer smartphone app)- Wireless teacher-student function, as well as DSC jack for teacher-student operation- Custom data jack for external modules, e.g. Crossfire or ELRS module- Internal 16 GB SD card- mp3 and wav player- Loudspeaker for voice messages and telemetry announcements- User definable haptic feedback (vibration alarm)- 4 x 3-way switches, 2 x 3-way switches/buttons, 2 x 2-way switches, 4 x proportional encoder, 2 x since 33040

The mz-32 is centered around youThe Graupner mz-32 is our third generation telemetry radio system that advances RC radios to a level never seen before. With its rich set of hardware and software features, the mz-32 is introducing a new level of functionality where you, the user, can control almost any part of the radio.Be in control with the mz-32The mz-32 brings you the power to design your own screens, program your own control logic, filter your own voice notifications and even design the looks of your radio.Fly smoother and beyond with the mz-32The Graupner mz-32 is the first radio on the market that provides full 32 channel functions right out of the box! It supports five different model types such as electric, gas or turbine airplanes, helicopters, multirotor, cars and even boats.It can store and load up to 999 different user models, has 12 flight-phases and 16 curve mixers which can be set global or flight-phase dependent! The hall sensor 4096 resolution quad bearing gimbals provide the smoothest control feel a pilot can experience. The sealed gimbals can weather almost any field conditions and offer easy back-access for adjustment to fine-tune the stick tension the way you like.The mz-32 has a dual 2.4GHz redundant RF system driving a polarized patch antenna for unmatched signal quality and extended range. The included 9000mAh LiPo battery will provide more than 10 hours of operating time, which makes a long day at the field both possible and fun!The mz-32 adapts to youThe outdoor friendly 4.3-inch state of the art TFT color touchscreen ensures convenient access to all the mz-32 functions for setting up and managing your models.The highly optimized and fast performing graphical user interface is driven by a high-performance processor making access to menus and functions fast and crisp just like on your Smartphone. The intuitive touch and tap control makes navigation around the menus fast, easy and fun!The mz-32 is not only fast and responsive but is also fast to load. You will be using your mz-32 from power up in 10 seconds!Designing your own screen layouts to display information or create menu shortcuts can be done on the fly by simply tapping on the screen.The mz-32 provides over hundred widgets which make up the screens that you like and fit your style for controlling your models.You can create in total six screens that better fit your needs and personal style using the tip of your finger. No programming needed! You can do it all with the mz-32.One radio for all! German, English, French and Italian language is supported with more languages to come all in one radio!More channels more control for youWith 32 channels the mz-32 provides unlimited functionality and control over any model that you have. You can bind up to four 2.4GHz receivers so you can layout and distribute the channels the way you want.For example, you can have two six-channel receivers for each wing from where you can control ailerons, flaps, landing gear, and lights. Just supply main power to the wing, and you are ready to go.No complicated wiring or expensive hubs needed! This provides you with a level of simplicity with the benefits of RF redundancy unseen before in the industry.Still need more channels but do not have enough switches to do what you want? The mz-32 now also provides up to 64 digital switches that can be assigned and controlled from the widget menu with a simple tap. Create as many digital switch combinations as you like for turning lights and smoke on or off, turn cranes or water guns or anything else that you need to control without using up your switches.Switching and control options are further enhanced with Logical Switches (And, Or, Equal, Not), Control Switches, and Combination Switches. Each provides a new level of control to you depending on switch position or stick location.Voices you want to hearNeed to hear what is going on? The mz-32 provides endless options to generate almost any type of system or telemetry voice notification depending on the state of your radio such as switch positions, flight phase names, warnings, vario information and endless others.The mz-32 starts communicating with you from the moment you turn it on, informing you if a switch or control is in the wrong position for the selected model. No more surprises from collapsing landing gear, runaway motors or wrong gyro settings. The mz-32 can inform you when needed even when you forgot to bring down your landing gear or are about to run out of range or battery.Walks of shame are now a thing of the past!With over 600 installed voices and unlimited voice combinations, you can make almost any voice announcements or add as many as you want using our text to speech editor.Instant help where you need itIn need of help during setup or when something is unclear? Forget about searching through lengthy manuals or endless web searches! The mz-32 provides support right where you need. Each menu and option has its own context-sensitive answers right on the screen. Just tap the question mark and you will be instantly presented with help and assistance.Don’t like our help screens? Make or add your own help screens with whatever makes sense to you. The mz-32 is there for you allowing you to do and have the things you like the most.Connectivity that takes you furtherWith integrated Bluetooth and Wi-Fi the mz-32 is ready to connect you with the rest of the world! Use your Bluetooth headset to hear voice alerts or music from the built-in music player. It's your choice!Connect to your wireless LAN to receive notifications about newly released firmware that are instantly downloaded and installed on your radio. Your mz-32 is always up to date with the latest and greatest! The update can also be done by using the included USB cable and the latest firmware which you can always find on our website.Graupner takes connectivity further with a micro USB port that can charge your radio, access your included 16GB micro SD memory card where screens, models, voice files, music and screen shots are stored.You can use the USB or DSC port also as a joystick controller for games and flight simulators. Now you can practice flying your model on your favorite flight simulator with the same radio that you use at the field!The data port on the back can be configured to output a variety of digital signal outputs like SUMD, CROSSFIRE, Smart Box, and more. Adding and using third-party modules such as long-range FPV has never been easier than with the mz-32.All Graupner HoTT receivers now also support digital single wire output such as PPM, SUMD, and SBUS for more connectivity and better interoperability.The built-in file manager lets you manage things like voice files, screenshots, and more from wherever you are!Supported Protocols:HoTT-PCSmart-BoxExternal MonitorSUMDDSMX, DSM2 (Data Output)CROSSFIRE V1/V2Wireless controllers setupComputers, wirers, and programming boxes are things of the past! The mz-32 HoTT wireless protocol lets you do everything right on the radio! Need to set up your telemetry, flight controller or reverse the direction of your telemetry ESC or flight controller? Just use the shortcut key on the radio to access any of the receiver connected devices, and you are immediately in business. Do this at home while setting up your model or at the field to fine-tune your settings.Enjoy the HoTT integration of third-party flight controllers and sensors like Ikon, Spirit, 3Digi, MSH-Brain, SM Modelbau and many more for easy access using only your mz-32 radio. Each of Graupner's HoTT receivers provides this functionality, and there is no need to purchase anything else to use these convenient features.Train your buddiesTraining your family members or friends is as easy as bind and teach! The mz-32 provides a wireless and wired trainer support that can be used with any of our HoTT radios using the DSC port in the back.You can assign control to any of the active channels depending on your student's level and model capabilities. Passing control is easily done with a flick of a switch.HARDWAREHall Sensor quad bearing gimbals with 4096 resolutions for smooth and precise controlOutdoor friendly 4.3-inch TFT color and touch screenRedundant dual 2.4GHz RF modulesCircular polarized patch antenna with adjustable beam angle9000 mAh LiHV rechargeable battery for up to 10 hours of operationMicro-USB port for charging, data communication, joystick function or mass storageExternally adjustable stick tension and mode selectionInternal µSD 16 Gb memory cardBuilt in Wireless and Bluetooth communicationDSC socket for external communications (wired buddy box, flight simulators, other)Wireless student teacher operationWireless firmware updateIntegrated speaker for voice output and telemetry notificationsUser configurable DSC and data ports (SUMD, CROSSFIRE and others)User assignable haptic feedback5 x 3 position switches, 2 x 3 position/toggle switches, 1 x 2 position switch, 4 proportional knobs, 2 x lever controls, 8 assignable digital buttons6 shortcut control and navigation keysSOFTWARE32 proportional channels999 Model memory4 Receiver binding 10ms or 20ms frame rateModel, group or global binding modesModel types: Airplane, Helicopter, Multirotor, Vehicle, Boat12 selectable flight modes8 wing types, 6 delta wing types, 3 tail typesMulti engine control (4)6 user designable widgets dashboards (model specific or global)Context sensitive help textAirplane auto trim modeText to speech with VDF editorServo balancer & synchronization8 phase dependent assignable trim settings and 5 trim types6 phase dependent configurable timers (Start/Stop, Lap, Lap Trigger, Lap Toggle)8 phase dependent quad rate and expo settings16 phase dependent multi point user mixers8 dual differential mixers3 channel sequencers3 channel ring limiters64 user assignable digital switches12 assignable combination switches12 assignable logical switches12 assignable control switches4 snap roll mixes8 wing and tail mixers and crow/butterfly function9 user assignable and configurable system voice notifications8 user assignable and configurable user voice notifications24 user assignable and configurable control voice notifications8 user assignable and configurable voice notificationsDedicated vario and control menu with dead zone controlWireless setup of receivers, telemetry and flight controllersUser configurable MP3 playerIntegrated file manager S1024.77

Especially suitable for motor and glider models, helicopters, boat models and RC-Car. Graupner servos represent a product line which provides the right servo for almost every application with a wide range of specifications. Different sizes, gear designs, actuating forces and actuating times designed for the beginner to the competition pilot. - C Series: proven analogue servos from JR, proven a thousand times over- DS series: digital servos from JR, extremely precise neutral position and smooth control characteristics due to 13 bit ACD system with 5,900 steps- DES series: low-cost digital servos, for universal applications in model making with high-quality Atmel microcontroller- HVS series; High-Voltage servos for direct connection to 2-cell Lipo batteries - HBS series: High-Voltage - Brushless servos for direct connection to 2-cell lipo batteries, with incomparable acceleration behaviour- HVC / HCM series: High-Voltage - Corless Servos for direct connection to 2-cell Lipo batteries, highest production quality, some with metal housing (HCM) 7952

Especially suitable for motor- and glider models, boat models and RC-Car. Graupner servos represent a product line which provides the right servo for almost every application with a wide range of specifications. Different sizes, gear designs, actuating forces and actuating times designed for the beginner to the competition pilot. - C Series: proven analogue servos from JR, proven a thousand times over- DS series: digital servos from JR, extremely precise neutral position and smooth control characteristics due to 13 bit ACD system with 5,900 steps- DES series: low-cost digital servos, for universal applications in model making with high-quality Atmel microcontroller- HVS series; High-Voltage servos for direct connection to 2-cell Lipo batteries - HBS series: High-Voltage - Brushless servos for direct connection to 2-cell lipo batteries, with incomparable acceleration behaviour- HVC / HCM series: High-Voltage - Corless Servos for direct connection to 2-cell Lipo batteries, highest production quality, some with metal housing (HCM) 7946

Especially suitable for motor and glider models, micro helicopters and RC boat models.warning notes of the company Graupner/SJ! Possible malfunction with this servoWith this servo with metal gear the potentiometer operating voltage is transmitted to the metal axis of the servo. The use of aluminium control horns or a non-insulated RDS linkage with a conductive connection, e.g. in a full carbon fibre model, causes mutual interference between the servos, as the above-mentioned voltage is transmitted. Therefore please use either plastic control surface horns or insulate the mountings so that there is no electrical connection.The Graupner/SJ GmbH company as manufacturer recommends that you use only components and accessories which have been tested for suitability and safety by Graupner/SJ and which have been approved for use. In this case Graupner/SJ will assume product responsibility for you. Graupner/SJ accepts no liability for non-approved parts or accessory products from other manufacturers and cannot evaluate every single third-party product. Whether it can be used without safety risk. Graupner servos represent a product line which provides the right servo for almost every application with a wide range of specifications. Different sizes, gear designs, actuating forces and actuating times designed for the beginner to the competition pilot. - C Series: proven analogue servos from JR, proven a thousand times over- DS series: digital servos from JR, extremely precise neutral position and smooth control characteristics due to 13 bit ACD system with 5,900 steps- DES series: low-cost digital servos, for universal applications in model making with high-quality Atmel microcontroller- HVS series; High-Voltage servos for direct connection to 2-cell Lipo batteries - HBS series: High-Voltage - Brushless servos for direct connection to 2-cell lipo batteries, with incomparable acceleration behaviour- HVC / HCM series: High-Voltage - Corless Servos for direct connection to 2-cell Lipo batteries, highest production quality, some with metal housing (HCM) 7932

Don't let the small size fool you: you will be surprised by the precision, torque and speed that the DES 261 BB can deliver, making it the perfect choice for indoor, outdoor and park flyer models. 7903

Especially suitable for motor- and glider models, boat models and RC-Off-Road-Car, M 1:8 and 1:5. Do not use in full carbon fiber surfaces with RDS linkage with electrical connection or with aluminum levers! The gearbox or the RDS linkage or the alloy levers must be electrically insulated! 2 x ball bearingMetal gearboxes 7945

Especially suitable for indoor models and park flyers.- Mounting dimensions in relation to output the same as C261 servo- Smallest dimensions- Absolutely light weight- Parameters adjustable via PC software- ball bearings- metal gearbox Designed with precision components for durability and long-life operations, the Graupner DES 261 BB Digital Micro-Servo delivers maximum torque and speed with minimum weight. Don’t be fooled by the small size: you will be surprised with the precision, torque and speed the DES 261 BB can deliver, making it the perfect choice for indoor, outdoor and park flyer models. The DES 261 BB can be specially programmed to meet all your needs via the free Graupner Servo Setup Software.FEATURESDigital servo featuring dynamic torque, excellent Speed, superior response and holding torqueProgrammable Digital Circuit and SMT circuitry1024 high resolutionSupporting 1-16µ depending on programmingSupports a wide range of frame rates 20Hz-400Hz10-bit processing circuit 7905

Especially well suited for motor powered and glider aircraft models, helicopters, boat models, and RC cars.High-voltage, operating voltage up to 8.4V!Direct operation with 2-cell LiPo batteriesOperating voltage range 4.8 ... 8.4 VBall bearingsMetal drive mechanismWarning - Potential problems with this servo!This servo features metal gears, and the potentiometer operating voltage is passed to the servo’s metal output shaft. If an aluminium control surface horn or a non-insulated RDS linkage is used with the servo, and if an electrically conductive contact with the airframe also exists - e.g. in an all-carbon model - the servos will interact with each, as the aforesaid voltage is transmitted between them. You can avoid this problem either by using a plastic control surface horn, or by insulating the servo mount in such a way that no electrical connection exists.As manufacturer, Graupner/SJ GmbH recommends the exclusive use of accessories which have been tested and approved by Graupner/SJ, as this ensures that they are fit for purpose, work correctly and are safe. If you observe this advice, Graupner/SJ accepts liability to you for the product. Graupner/SJ is not in a position to assess the safety risk of every individual product made by other companies. For this reason we deny all liability If you use non-approved components, or accessories made by other manufacturers. Designed with precision components for durability and long-life operations, the Graupner DES 261 BB Digital Micro-Servo delivers maximum torque and speed with minimum weight. Don’t be fooled by the small size: you will be surprised with the precision, torque and speed the DES 261 BB can deliver, making it the perfect choice for indoor, outdoor and park flyer models. The DES 261 BB can be specially programmed to meet all your needs via the free Graupner Servo Setup Software.FEATURESDigital servo featuring dynamic torque, excellent Speed, superior response and holding torqueProgrammable Digital Circuit and SMT circuitry1024 high resolutionSupporting 1-16µ depending on programmingSupports a wide range of frame rates 20Hz-400Hz10-bit processing circuit 7965

Besonders geeignet für Motor- und Segelflugmodelle, Helikopter, Bootsmodelle und RC-Car. Designed with precision components for durability and long-life operations, the Graupner DES 261 BB Digital Micro-Servo delivers maximum torque and speed with minimum weight. Don’t be fooled by the small size: you will be surprised with the precision, torque and speed the DES 261 BB can deliver, making it the perfect choice for indoor, outdoor and park flyer models. The DES 261 BB can be specially programmed to meet all your needs via the free Graupner Servo Setup Software.FEATURESDigital servo featuring dynamic torque, excellent Speed, superior response and holding torqueProgrammable Digital Circuit and SMT circuitry1024 high resolutionSupporting 1-16µ depending on programmingSupports a wide range of frame rates 20Hz-400Hz10-bit processing circuit 7943

Besonders geeignet für Motor- und Segelflugmodelle sowie Helikopter. Designed with precision components for durability and long-life operations, the Graupner DES 261 BB Digital Micro-Servo delivers maximum torque and speed with minimum weight. Don’t be fooled by the small size: you will be surprised with the precision, torque and speed the DES 261 BB can deliver, making it the perfect choice for indoor, outdoor and park flyer models. The DES 261 BB can be specially programmed to meet all your needs via the free Graupner Servo Setup Software.FEATURESDigital servo featuring dynamic torque, excellent Speed, superior response and holding torqueProgrammable Digital Circuit and SMT circuitry1024 high resolutionSupporting 1-16µ depending on programmingSupports a wide range of frame rates 20Hz-400Hz10-bit processing circuit 7935

Besonders geeignet für Motor- und Segelflugmodelle, Micro Helikopter und RC-Car. Designed with precision components for durability and long-life operations, the Graupner DES 261 BB Digital Micro-Servo delivers maximum torque and speed with minimum weight. Don’t be fooled by the small size: you will be surprised with the precision, torque and speed the DES 261 BB can deliver, making it the perfect choice for indoor, outdoor and park flyer models. The DES 261 BB can be specially programmed to meet all your needs via the free Graupner Servo Setup Software.FEATURESDigital servo featuring dynamic torque, excellent Speed, superior response and holding torqueProgrammable Digital Circuit and SMT circuitry1024 high resolutionSupporting 1-16µ depending on programmingSupports a wide range of frame rates 20Hz-400Hz10-bit processing circuit 7931

Suitable for RC model aircraft and boats. Do not use in carbon wings with RDS. Voltage of potentiometer on the gear must be isulated to carbon parts.Warning - Potential problems with this servo!This servo features metal gears, and the potentiometer operating voltage is passed to the servo’s metal output shaft. If an aluminium control surface horn or a non-insulated RDS linkage is used with the servo, and if an electrically conductive contact with the airframe also exists - e.g. in an all-carbon model - the servos will interact with each, as the aforesaid voltage is transmitted between them. You can avoid this problem either by using a plastic control surface horn, or by insulating the servo mount in such a way that no electrical connection exists.As manufacturer, Graupner/SJ GmbH recommends the exclusive use of accessories which have been tested and approved by Graupner/SJ, as this ensures that they are fit for purpose, work correctly and are safe. If you observe this advice, Graupner/SJ accepts liability to you for the product. Graupner/SJ is not in a position to assess the safety risk of every individual product made by other companies. For this reason we deny all liability If you use non-approved components, or accessories made by other manufacturers. Designed with precision components for durability and long-life operations, the Graupner DES 261 BB Digital Micro-Servo delivers maximum torque and speed with minimum weight. Don’t be fooled by the small size: you will be surprised with the precision, torque and speed the DES 261 BB can deliver, making it the perfect choice for indoor, outdoor and park flyer models. The DES 261 BB can be specially programmed to meet all your needs via the free Graupner Servo Setup Software.FEATURESDigital servo featuring dynamic torque, excellent Speed, superior response and holding torqueProgrammable Digital Circuit and SMT circuitry1024 high resolutionSupporting 1-16µ depending on programmingSupports a wide range of frame rates 20Hz-400Hz10-bit processing circuit 7923

This digital servo is the ideal surface servo for your model due to its extremely slim design and highest positioning accuracy. The double ball-bearing precision gear made of metal ensures precise positioning characteristics at high force and speed. Additional, universally applicable mounting brackets allow a comfortable and flexible mounting of the servo even lying on the wing. The perfect solution for cramped mounting conditions. Designed with precision components for durability and long-life operations, the Graupner DES 261 BB Digital Micro-Servo delivers maximum torque and speed with minimum weight. Don’t be fooled by the small size: you will be surprised with the precision, torque and speed the DES 261 BB can deliver, making it the perfect choice for indoor, outdoor and park flyer models. The DES 261 BB can be specially programmed to meet all your needs via the free Graupner Servo Setup Software.FEATURESDigital servo featuring dynamic torque, excellent Speed, superior response and holding torqueProgrammable Digital Circuit and SMT circuitry1024 high resolutionSupporting 1-16µ depending on programmingSupports a wide range of frame rates 20Hz-400Hz10-bit processing circuit 7914

The DES 577 BB delivers high torque, high speed and high holding power. The SMT circuitry makes the DES 577 BB the perfect choice for gliders, helicopters, boats and cars. Designed with precision components for durability and long-life operations, the Graupner DES 261 BB Digital Micro-Servo delivers maximum torque and speed with minimum weight. Don’t be fooled by the small size: you will be surprised with the precision, torque and speed the DES 261 BB can deliver, making it the perfect choice for indoor, outdoor and park flyer models. The DES 261 BB can be specially programmed to meet all your needs via the free Graupner Servo Setup Software.FEATURESDigital servo featuring dynamic torque, excellent Speed, superior response and holding torqueProgrammable Digital Circuit and SMT circuitry1024 high resolutionSupporting 1-16µ depending on programmingSupports a wide range of frame rates 20Hz-400Hz10-bit processing circuit 7944

Besonders geeignet für RC-Flugmodelle, Micro Helikopter und RC-Bootsmodelle. Designed with precision components for durability and long-life operations, the Graupner DES 261 BB Digital Micro-Servo delivers maximum torque and speed with minimum weight. Don’t be fooled by the small size: you will be surprised with the precision, torque and speed the DES 261 BB can deliver, making it the perfect choice for indoor, outdoor and park flyer models. The DES 261 BB can be specially programmed to meet all your needs via the free Graupner Servo Setup Software.FEATURESDigital servo featuring dynamic torque, excellent Speed, superior response and holding torqueProgrammable Digital Circuit and SMT circuitry1024 high resolutionSupporting 1-16µ depending on programmingSupports a wide range of frame rates 20Hz-400Hz10-bit processing circuit 7936

Specially suitable for indoor models and parkflyers. Smallest dimensions. Absolutely low weight. Designed with precision components for durability and long-life operations, the Graupner DES 261 BB Digital Micro-Servo delivers maximum torque and speed with minimum weight. Don’t be fooled by the small size: you will be surprised with the precision, torque and speed the DES 261 BB can deliver, making it the perfect choice for indoor, outdoor and park flyer models. The DES 261 BB can be specially programmed to meet all your needs via the free Graupner Servo Setup Software.FEATURESDigital servo featuring dynamic torque, excellent Speed, superior response and holding torqueProgrammable Digital Circuit and SMT circuitry1024 high resolutionSupporting 1-16µ depending on programmingSupports a wide range of frame rates 20Hz-400Hz10-bit processing circuit 7903.LOSE

Especially suitable for motor and glider models as well as micro-helicopters.warning notes of the company Graupner/SJ! Possible malfunction with this servoWith this servo with metal gear the potentiometer operating voltage is transmitted to the metal axis of the servo. The use of aluminium control horns or a non-insulated RDS linkage with a conductive connection, e.g. in a full carbon fibre model, causes mutual interference between the servos, as the above-mentioned voltage is transmitted. Therefore please use either plastic control surface horns or insulate the mountings so that there is no electrical connection.The Graupner/SJ GmbH company as manufacturer recommends that you use only components and accessories which have been tested for suitability and safety by Graupner/SJ and which have been approved for use. In this case Graupner/SJ will assume product responsibility for you. Graupner/SJ accepts no liability for non-approved parts or accessory products from other manufacturers and cannot evaluate every single third-party product. Whether it can be used without safety risk. Graupner servos represent a product line which provides the right servo for almost every application with a wide range of specifications. Different sizes, gear designs, actuating forces and actuating times designed for the beginner to the competition pilot. - C Series: proven analogue servos from JR, proven a thousand times over- DS series: digital servos from JR, extremely precise neutral position and smooth control characteristics due to 13 bit ACD system with 5,900 steps- DES series: low-cost digital servos, for universal applications in model making with high-quality Atmel microcontroller- HVS series; High-Voltage servos for direct connection to 2-cell Lipo batteries - HBS series: High-Voltage - Brushless servos for direct connection to 2-cell lipo batteries, with incomparable acceleration behaviour- HVC / HCM series: High-Voltage - Corless Servos for direct connection to 2-cell Lipo batteries, highest production quality, some with metal housing (HCM) 7919

Besonders geeignet für Motor- und Segelflugmodelle Designed with precision components for durability and long-life operations, the Graupner DES 261 BB Digital Micro-Servo delivers maximum torque and speed with minimum weight. Don’t be fooled by the small size: you will be surprised with the precision, torque and speed the DES 261 BB can deliver, making it the perfect choice for indoor, outdoor and park flyer models. The DES 261 BB can be specially programmed to meet all your needs via the free Graupner Servo Setup Software.FEATURESDigital servo featuring dynamic torque, excellent Speed, superior response and holding torqueProgrammable Digital Circuit and SMT circuitry1024 high resolutionSupporting 1-16µ depending on programmingSupports a wide range of frame rates 20Hz-400Hz10-bit processing circuit 7911

Especially suitable for motor and glider models.Graupner servos represent a product line which supplies the right servo with the most varied specifications for almost every field of application. Different sizes, gear designs, actuating forces and actuating times designed for the beginner to the competition pilot.C Series: proven analog servos from JR, proven a thousand times overDS series: digital servos from JR, extremely precise neutral position and smooth control characteristics through 13 bit ACD system with 5,900 stepsDES series: low-cost digital servos, for universal applications in model making with high-quality Atmel microcontrollerHVS series; High-Voltage servos for direct connection to 2-cell Lipo batteriesHBS series: High-Voltage - Brushless servos for direct connection to 2-cell lipo batteries, with an incomparable acceleration performanceHVC / HCM series: High-Voltage - Corless Servos for direct connection to 2-cell Lipo batteries, highest production quality, partly with metal housing (HCM) Designed with precision components for durability and long-life operations, the Graupner DES 261 BB Digital Micro-Servo delivers maximum torque and speed with minimum weight. Don’t be fooled by the small size: you will be surprised with the precision, torque and speed the DES 261 BB can deliver, making it the perfect choice for indoor, outdoor and park flyer models. The DES 261 BB can be specially programmed to meet all your needs via the free Graupner Servo Setup Software.FEATURESDigital servo featuring dynamic torque, excellent Speed, superior response and holding torqueProgrammable Digital Circuit and SMT circuitry1024 high resolutionSupporting 1-16µ depending on programmingSupports a wide range of frame rates 20Hz-400Hz10-bit processing circuit 7910

Mit dem Hawk 18 präsentiert Graupner einen leistungsstarken 9-Kanal-Empfänger mit integriertem 3-Achs Gyro und besonders vibrationsunempfindliche 3-Achs Beschleunigungssensor, Diversity-Antennen, Vario und Lagemodus für Flächenmodell oder Rettungsmodus und Lagemodus für Helikopter.Mit der GRAUPNER HoTT 2,4GHz-Technologie verfügt der Empfänger über ein sicheres Hopping-Telemetry-Transmission-Hochfrequenzteil mit hochwertigen Komponenten und modernster Software. Der Empfänger übermittelt ohne Zusatz-Sensorik die Parameter „Empfängerspannung“, „Empfängertemperatur“ , „Signalstärke“, „Höhe“, „Höhendifferenz (Vario)“ an den Sender. Weiterhin ist es möglich die Eulerwinkel an den Sender zu übertragen und dort anzuzeigen.Der Antennenverstärker sorgt zusammen mit dem Antennendiversity für eine enorme Reichweite. Der schnellere 32-Bit L4 Prozessor ist ein Garant für stromsparendes Arbeiten und die höhere Leistungsfähigkeit sorgt dafür, dass der Hawk 18 auch als Flybarless System für Helicopter und als Flightcontroller für Copter verwendet werden kann. Selbstverständlich kann das integrierte Hawk Kreiselsystem auch perfekt für Flächenmodelle genutzt werden. Hier gibt es 4 verschiedene Gyromodi: AUS, normale Stabilisierung, Heading Lock, Drehratenmodus und Lagemodus. Der Drehratenmodus ermöglicht es bei korrekter Einstellung einen Messerflug und Torquen ohne Steuerkorrekturen durchzuführen. Extrem schnell, einfach und komfortabel einstellbar über das Hott-Sender Telemetrie-Menü.Genau wie sein Namensgeber, der Falke, verkörpert der Hawk 18 Zielstrebigkeit, Kraft und Präzision. Gehen Sie mit dem Hawk auf die Jagd nach dem perfekten Flug.FlächenmodelleStabilisierung des Flugmodells bei schwierigen Windverhältnissen für bis zu 3 AchsenNatürliches Flugverhalten durch proportionale KreiselausblendungDurch den 3-Achs Kreisel lassen sich auch schwierig zu beherschende Kunstflugmodelle sehr gutmütig fliegen und Kunstflug wird extrem vereinfachtFlugfiguren lassen sich deutlich sauberer fliegen4 verschiedene Gyromodi: AUS, normale Stabilisierung, Heading lock, Drehratenmodus für besonders einfachen Messerflug und einfaches Torquen sowie LagemodusEinfache Einstellung der KreiselzuweisungEinstellung der Parameter über die HoTT-TelemetrieSoftware mit Lagemodus ermöglicht einfache Landungen auch bei schwierigen Windverhältnissen5 freie MischerSUMD Ausgang für den Anschluss an Flybarless-Systeme, Flight Controller oder an eine Power-Box.SUMDIN Eingang für redundanten Empfängerbetrieb.Flybarlesssystem für HelikopterRettungmodus und Lagemodus für HelikopterGrundeinstellung in wenigen Minuten über die HoTT-Telemetrie durchgeführtSchnelle und Innovative Achszuordnung dadurch flexible EinbaurichtungDurch Größe, Gewicht und Wegfall von Kabeln extrem platzsparend, dadurch einfache UnterbringungSpeziell Vibrationsunempfindliche 3 Achs-Sensoren der neusten GenerationPirouetten-Optimierung der Taumelscheibe und Richtung des Heckdrehmomentausgleiches werden automatisch erkanntAlle gängigen Heli-Taumelscheiben 90/120/135/140 Grad und 90 Grad 4 ServosEinstellbare Taumelscheibendrehung bis 90 Grad für MehrblattköpfeÜbersichtliches Standard und bei Bedarf wählbares Experten MenüEmpfindlichkeit Parameter während des Flugs auf Drehzahl und Stil auch Flugphasenabhängig über Geber anpassbarSuperschnell durch Wegfall der Übertragungszeit vom Empfänger zum Flybarless-SystemSehr direktes SteuergefühlProgrammierung für HelikopterEinfache Programmierung der Grundeinstellungen über die Telemetrie.Die Pirouettenoptimierung wird aus den Parametern automatisch ermittelt und funktioniert extrem gut.Extreme Flugstabilität bei gleichzeitiger voller 3D Tauglichkeit auch schon mit den Grundeinstellungen.Wirkung für Heck und Taumelscheibe einfach über das Telemetriemenü oder über auswählbare Geber einstellbar.Weitere Optimierungsmöglichkeiten im Expertenmodus für den persönlichen Flugstiel und die persönlichen Belange.Extrem einfache Einstellung der Grundeinstellungen über die Telemetrie:RotordrehrichtungTaumelscheibentypTaumelscheibenfrequenz 50...200 HzTaumelscheibenrichtungTaumelscheiben Servomitten Servo 1...3 (4)Taumelscheiben zykl. Weg auf 8° einstellenTaumelscheiben Pitchweg A/BTaumelscheibenlimitTaumelscheibendrehungHeckservo Mittenimpuls 760µs, 960µs, 1,5 msHeckservofrequenz 50...333 HzHeckservo MittelstellungRettungspitchExpo ja/neinLogging für Servicezwecke oder für die EulerwinkelanzeigeExpertenmodus ja/neinEinfache KreiselachsenzuordnungKreiselwirkung für Heck und Taumelscheibe über die Telemetrie oder einstellbare Geber.Im Expertenmodus können weitere Parameter eingestellt werden.Technische DatenKanäle: 9Abmessungen ca.: 46 x 21 x 14 mmGewicht ca.: 14 gFrequenz: 2400 ... 2483.5 MHzModulation: 2.4 GHz FHSSReichweite: ca. 4000 mStromaufnahme: 70 mABetriebsspannung: 3,7V bis 8,4VAntennenlänge: 2x Draht 145 (Antenne 30) mmTemperaturbereich: -15 bis +70°C S1053

Mit dem Hawk 12 präsentiert Graupner einen leistungsstarken 6-Kanal-Empfänger mit integriertem 3-Achs Gyro und besonders vibrationsunempfindliche 3-Achs Beschleunigungssensor, Diversity-Antennen, Vario und Lagemodus für Flächenmodell oder Rettungmodus und Lagemodus für Helikopter.Mit der GRAUPNER HoTT 2,4GHz-Technologie verfügt der Empfänger über ein sicheres Hopping-Telemetry-Transmission-Hochfrequenzteil mit hochwertigen Komponenten und modernster Software. Der Empfänger übermittelt ohne Zusatz-Sensorik die Parameter „Empfängerspannung“, „Empfängertemperatur“ , „Signalstärke“, „Höhe“, „Höhendifferenz (Vario)“ an den Sender. Weiterhin ist es möglich die Eulerwinkel an den Sender zu übertragen und dort anzuzeigen.Der Antennenverstärker sorgt zusammen mit dem Antennendiversity für eine enorme Reichweite. Der schnellere 32-Bit L4 Prozessor ist ein Garant für stromsparendes Arbeiten und die höhere Leistungsfähigkeit sorgt dafür, dass der Hawk 12 auch als Flybarless System für Helicopter und als Flightcontroller für Copter verwendet werden kann. Selbstverständlich kann das integrierte Hawk Kreiselsystem auch perfekt für Flächenmodelle genutzt werden. Hier gibt es 4 verschiedene Gyromodi: AUS, normale Stabilisierung, Heading Lock, Drehratenmodus und Lagemodus. Der Drehratenmodus ermöglicht es bei korrekter Einstellung einen Messerflug und Torquen ohne Steuerkorrekturen durchzuführen. Extrem schnell, einfach und komfortabel einstellbar über das Hott-Sender Telemetrie-Menü.Genau wie sein Namensgeber, der Falke, verkörpert der Hawk 12 Zielstrebigkeit, Kraft und Präzision. Gehen Sie mit dem Hawk auf die Jagd nach dem perfekten Flug.FlächenmodelleStabilisierung des Flugmodells bei schwierigen Windverhältnissen für bis zu 3 AchsenNatürliches Flugverhalten durch proportionale KreiselausblendungDurch den 3-Achs Kreisel lassen sich auch schwierig zu beherrschende Kunstflugmodelle sehr gutmütig fliegen und Kunstflug wird extrem vereinfachtFlugfiguren lassen sich deutlich sauberer fliegen4 verschiedene Gyromodi: AUS, normale Stabilisierung, Heading lock, Drehratenmodus für besonders einfachen Messerflug und einfaches Torquen sowie LagemodusEinfache Einstellung der KreiselzuweisungEinstellung der Parameter über die HoTT-TelemetrieSoftware mit Lagemodus ermöglicht einfache Landungen auch bei schwierigen Windverhältnissen5 freie MischerSUMD Ausgang für den Anschluss an Flybarless-Systeme, Flight Controller oder an eine Power-Box.SUMDIN Eingang für redundanten Empfängerbetrieb.Flybarlesssystem für HelikopterRettungsmodus und Lagemodus für HelikopterGrundeinstellung in wenigen Minuten über die HoTT-Telemetrie durchgeführtSchnelle und Innovative Achszuordnung dadurch flexible EinbaurichtungDurch Größe, Gewicht und Wegfall von Kabeln extrem platzsparend, dadurch einfache UnterbringungSpeziell Vibrationsunempfindliche 3 Achs-Sensoren der neusten GenerationPirouetten-Optimierung der Taumelscheibe und Richtung des Heckdrehmomentausgleiches werden automatisch erkanntAlle gängigen Heli-Taumelscheiben 90/120/135/140 Grad und 90 Grad 4 ServosEinstellbare Taumelscheibendrehung bis 90 Grad für MehrblattköpfeÜbersichtliches Standard und bei Bedarf wählbares Experten MenüEmpfindlichkeit Parameter während des Flugs auf Drehzahl und Stil auch Flugphasenabhängig über Geber anpassbarSuperschnell durch Wegfall der Übertragungszeit vom Empfänger zum Flybarless-SystemSehr direktes SteuergefühlProgrammierung für HelikopterEinfache Programmierung der Grundeinstellungen über die Telemetrie.Die Pirouettenoptimierung wird aus den Parametern automatisch ermittelt und funktioniert extrem gut.Extreme Flugstabilität bei gleichzeitiger voller 3D Tauglichkeit auch schon mit den Grundeinstellungen.Wirkung für Heck und Taumelscheibe einfach über das Telemetriemenü oder über auswählbare Geber einstellbar.Weitere Optimierungsmöglichkeiten im Expertenmodus für den persönlichen Flugstiel und die persönlichen Belange.Extrem einfache Einstellung der Grundeinstellungen über die Telemetrie:RotordrehrichtungTaumelscheibentypTaumelscheibenfrequenz 50...200 HzTaumelscheibenrichtungTaumelscheiben Servomitten Servo 1...3 (4)Taumelscheiben zykl. Weg auf 8° einstellenTaumelscheiben Pitchweg A/BTaumelscheibenlimitTaumelscheibendrehungHeckservo Mittenimpuls 760µs, 960µs, 1,5 msHeckservofrequenz 50...333 HzHeckservo MittelstellungRettungspitchExpo ja/neinLogging für Servicezwecke oder für die EulerwinkelanzeigeExpertenmodus ja/neinEinfache KreiselachsenzuordnungKreiselwirkung für Heck und Taumelscheibe über die Telemetrie oder einstellbare Geber.Im Expertenmodus können weitere Parameter eingestellt werden.Flight Control für CopterCoptersoftware Q07 mit Dshot-Reglerprotokoll per Softwareupdate aufspielbarGrundeinstellung in wenigen Minuten über das Telemetriemenü durchgeführtSchnelle und Innovative Achszuordnung dadurch flexible EinbaurichtungSpeziell Vibrationsunempfindliche 3 Achs-Sensoren der neusten GenerationDas Gehäuse schützt die Elektronik bei Crashs. Das spezielle Doppelklebeband dämpft zusätzlich die Vibrationen.8kHz Gyrofrequenz, Multishot und schnelle PID-Regelroutinen sowie neue Softwarefilter sorgen für ein perfektes Flugerlebnis.D-Shot mit Schildkrötenmodus.Quadrotyp XI (Quadrocopter X mit umgekehrter Propdrehrichtung), welche sich speziell bei FPV-Rennen bewährt hat, damit die Linse frei bleibt und die Props vom Hindernis wegdrehen.Bei Anschluss des GPS-Sensors S8437 an K5/Telemetrie und Einstellung K5 auf SENSOR stehen zusätzlich die Funktionen: GPS halten mit Höhenhaltung, Komm nach Hause und Wegpunkte abfliegen (mit HoTT Viewer App und USB-OTG-Kabel) zur Verfügung.Telemetrieunterstützung eigener Hott Sensoren und Hott Sensoren andere AnbieterSUMD Ausgang für andere Flybarlessempfänger.SUMDIN Eingang für redundanten Empfängerbetrieb.Spannungseingang für ext. Spannungsteiler, z. B. in den Reglern S3082 und S3083 bereits enthalten.HV tauglich. Eingangsspannungsbereich 3,6...8,4 VKann mit allen bisher erhältlichen HoTT-Sendern mit Telemetrie, programmiert und betrieben werdenTechnische DatenKanäle: 6Abmessungen ca.: 36 x 22 x 12 mmGewicht ca.: 10 gFrequenz: 2400 ... 2483.5 MHzModulation: 2.4 GHz FHSSReichweite: ca. 4000 mStromaufnahme: 70 mABetriebsspannung: 3,7V bis 8,4VAntennenlänge: 2x Draht 145 (Antenne 30) mmTemperaturbereich: -15 bis +70°C S1052

Performance and simplicity are the hallmarks of the Graupner GR-18AIR. Equipped with an integrated flight controller for flybarless helicopters and a 3-axis stabilisation gyro for aircraft, this is one of the most advanced 2.4 GHz receivers Graupner has ever made. The GR-18AIR is a long-range receiver with diversity antennas that uses Graupner's HoTT protocol to provide real-time telemetry data on signal strength, receiver voltage and temperature to help you improve situational awareness and safety during flight.Setting an aircraft or helicopter model or telemetry thresholds is done directly from your HoTT transmitter, wirelessly over the air. No computers or programming boxes required! Need to make a change to the PID or adjust the gyro? Just land and make the changes on the spot at the flying field, or you can assign a control to do it even in flight!The GR-18 can be upgraded with additional telemetry modules (GPS, OSD, ESC, vario telemetry, etc.) to continuously improve the reliability and performance of your system.FEATURESAircraft mode: Three-axis gyro stabilisation with remote gain/deflection control.Helicopter mode: flybarless control with remote gain control.Ultra-fast gyro and accelerometer sensors for fast and crisp responseWireless setup of all controller features and functionsBuilt-in telemetry for signal strength, temperatures and receiver voltageUpgradeable firmware with Graupner Firmware Update StudioNOTEThe GR-18AIR is identical to the GR-18 receiver except that it does not have a built-in altimeter (vario) and can only be used in aeroplane and helicopter modes. S1019.AIR

The Graupner GR-12L serial diversity receiver provides up to 16 (8, 12 or 16) control output channels using either SUMD, SBUS or SP2048 digital output signal.The GR-12L has a dual diversity antenna utilizing the HoTT protocol where it provides frequency hopping over 75 channels using the 2.4 GHz band making it therefore very reliable with minimal influences of external interference.The GR-12L serial receiver has built in telemetry for RSSI, temperature and receiver voltage and can be expanded with additional HoTT modules such as GPS, voltage modules and more.The GR-12L serial diversity receiver can operate under a wide range of voltage levels 3.6V to 8.4V (functional down to 2.5V) and with the enhanced receiver sensitivity the operating range has been substantially increased.The RSSI value can be output at CH8, CH12 or CH16 with SUMD, SBUS or SP2048.The very compact design and low weight (3 grams) makes it suitable for any multirotor, airplane or helicopter RC model.The GR-12L serial diversity receiver is designed to interface with third party flight controllers like Betaflight, Raceflight, Potenza, Bavarian Demon or flybarless controllers like Spirit, V-Stabi, Microbeast, Ikon, Neuron, 3Digi or any SUMD/SBUS/SP2048 flight controller.Features:Compact and light designWide voltage operation for extended reliability 3.6V to 8.4V (functional down to 2.5V)LED indicator shows receiver stateIncreased receiver sensitivity for extended rangeBuilt-in telemetry for signal strength, temperature and voltageAdjustable digital output signal and RSSI setting over HoTT telemetry radioBuilt-in failsafe and hold functionsTelemetry connection for additional sensors and modules S1051
