Robbe Modellsport RO-POWER TORQUE 6369 275 K/V BRUSHLESS MOTOR
Product number:
5813
GTIN/EAN:
9010189154051
Downloads
Description "Robbe Modellsport RO-POWER TORQUE 6369 275 K/V BRUSHLESS MOTOR"
Calculated measured values from eCalc:
RO-Power Torque Brushless motors are lightweight, powerful external rotor motors with high torque and efficiency. They do not require a gearbox and are suitable for a wide range of applications. All components are manufactured on modern CNC machines from high-quality materials. Precise ball bearings increase the service life and minimize vibrations. We recommend the operation of RO-Power Torque motors with ROBBE Ro-Control speed controllers.
RO-Power Torque-Anleitung-Manual-Manuel_DE-EN-FR_V9
- 8S 20x10" Robbe Dynamic electric approx. 80A (only short-time operation recommended!)
- 8S 21x8" APC electric approx. 75A
- 10S 18x8" Robbe Dynamic electric approx. 72A
- 10S 19x8" AERONAUT Cam Carbon approx. 80A (recommended for short-term operation only!)
RO-Power Torque Brushless motors are lightweight, powerful external rotor motors with high torque and efficiency. They do not require a gearbox and are suitable for a wide range of applications. All components are manufactured on modern CNC machines from high-quality materials. Precise ball bearings increase the service life and minimize vibrations. We recommend the operation of RO-Power Torque motors with ROBBE Ro-Control speed controllers.
- The accessory set must be ordered separately (not included in the scope of delivery)!
Manual
RO-Power Torque-Anleitung-Manual-Manuel_DE-EN-FR_V9
Technical data
| Housing-Ø (mm): | 63 |
|---|---|
| Housing length (mm): | 69 |
| LiPo (S): | 8-10 |
| Shaft-Ø (mm): | 8 |
| Propeller: | 20x10/18x8 |
| Weight (g): | 734 |
| Examples of use: | Akro + 3D bis 2,1m, Schlepper bis 2,2m |
| RPM/V: | 275 |
| Engine-type: | External rotor |
| recom. Controller: | RO-CONTROL PRO 14-130 6-14S -130(160)A |
| Innenwiderstand (mOhm): | 22,5 |
| Number of poles: | 14 |
| Leerlaufstrom (A): | 1,918 |
| Stromaufnahme max. (A): | 75 |
| Weight category (g): | 500 to 750 |
