Robbe Modellsport ROVOR SERVO S0270 MG BB
Product number:
S0270
€12.49*
Not in stock. Available approx. from 28.04.2026 to 07.07.2026.
| Bearing: | •• |
|---|---|
| Servo Speed sec./60°: | 0,12, 0,14 |
| Servo Torque kg/cm: | 3, 3,5 |
| Gearbox Type: | Metal |
| Weight (g): | 27 |
| Length (mm): | 31,6 |
| Width (mm): | 16,7 |
| Height (mm): | 30,0 |
| Servo-type: | Analog |
| Gear tooth: | 21Z/4,85mm |
| Opering voltage (V): | 4,8 - 6,0 |
| Torque kg/cm (4,8V): | 3 |
| Speed sec./60° (4,8V): | 0,14 |
| Torque kg/cm (6V): | 3,5 |
| Speed sec./60° (6V): | 0,12 |
Technical specifications
Type 15-19,5mm
Analog (A) yes
Metal gear unit (MG) yes
Motor 3-pole
Bearing 2
Speed 60° (sec.) 4,8V 0,14
Speed 60° (sec) 6V 0.12
Actuating force (KG) 4.8V 3
Actuating force (KG) 6V 3.5
Weight (grams) 27
L (mm) 31.2
B (mm) 16.3
H (mm) 29.5
Cable 250mm
Connector JR/Futaba
Teeth 21
Operating temperature in °C -10° to +50° C
Working angle 45° one-sided 500µsec
Power consumption 4.8V 20mA idle state, 120mA idle
Power consumption 6.0V 20mA idle state, 150mA idle
Power consumption standstill 4.8V 1.1A
Power consumption standstill 6.0V 1.3A
Dead band 4 µsec
Pulse (PWM) 1500 µsec
Type 15-19,5mm
Analog (A) yes
Metal gear unit (MG) yes
Motor 3-pole
Bearing 2
Speed 60° (sec.) 4,8V 0,14
Speed 60° (sec) 6V 0.12
Actuating force (KG) 4.8V 3
Actuating force (KG) 6V 3.5
Weight (grams) 27
L (mm) 31.2
B (mm) 16.3
H (mm) 29.5
Cable 250mm
Connector JR/Futaba
Teeth 21
Operating temperature in °C -10° to +50° C
Working angle 45° one-sided 500µsec
Power consumption 4.8V 20mA idle state, 120mA idle
Power consumption 6.0V 20mA idle state, 150mA idle
Power consumption standstill 4.8V 1.1A
Power consumption standstill 6.0V 1.3A
Dead band 4 µsec
Pulse (PWM) 1500 µsec
